MIL-DTL-46506E
PARAGRAPH TITLE
SHEET 1 OF 2
4.3.3
Assembly
INSPECTION
METHOD
Classification
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
CRITERIA
PARAGRAPH
None defined.
Critical
Major
101
Inside length, minimum
Level IV
3.14
Gage
102
Inside width, minimum
Level IV
3.14
Gage
103
Inside depth, minimum
Level IV
3.14
Gage
104
Decay exceeding 1/3 length or affecting serviceability
Level IV
3.8
Gage
of board cleat or batten
105
Hazardous splinters or sharp edges projecting
Level IV
3.22
Visual
106
Bulged or buckled wires
Level IV
3.22
Visual
107
Wood species not conforming to specification
Level IV
3.3
Visual
108
Board broken cross grain affecting utility of box
Level IV
3.4
Visual
109
Split full length in cleat or batten
Level IV
3.6.1
Visual
110
Split forming sliver at edge of board
Level IV
3.6.2
Visual
111
Top and bottom overlap not less than 1/4 inch
Level IV
3.15.1
Gage
112
Binding wires broken or missing
Level IV
3.11
Visual
113
Prong of binding wires not driven into wood
Level IV
3.15.2
Visual
114
End of wire not clinched
Level IV
3.15.3
Visual
115
Improper staple size over outer and intermediate wires
Level IV
3.12.1
Gage
116
Broken staples, four or more per outer wire
Level IV
3.12
Visual
117
Protruding nails or staple points
Level IV
3.13
Visual
118
Wire or staples not galvanized
Level IV
3.11.1
Visual
119
Short loop (preventing closing of box)
Level IV
3.11.5
Visual
120
Flaking or peeling of galvanized coating
Level IV
3.11.1
Visual
121
Hazardous splinters, sharp edges protruding, or bulged
Level IV
3.22
Visual
or buckled wires
122
Preservative treatment not completely dry
Level IV
3.19
Visual
123
Presence of heat treatment 2/
15
3.20
Visual
124
Load test of handles, rope or webbing
15
3.18.1
4.5.2.1
125
Determination of moisture content
15
3.17
4.5.1
126
Presence of wood preservative 1/
15
3.19
4.5.3, 4.5.4, 4.5.5
127
Binding wire tensile strength
N/A
3.11
3/
128
Stapling wire tensile strength
N/A
3.12
3/
Minor
201
Inside length, maximum
Level II
3.14
Gage
202
Inside width, maximum
Level II
3.14
Gage
203
Inside depth, maximum
Level II
3.14
Gage
204
Thickness of wood
Level II
3.9
Gage
205
Width of cleats and battens
Level II
3.10.1, 3.10.2
Gage
206
Wane on surface of board excessive
Level II
3.8.1
Gage
207
Sound knot or cluster of knots larger than 1/3 width of
Level II
3.7.1
Gage
wood
208
Sound knot larger than 1/4 width of cleat
Level II
3.7.2
Gage
14
