MIL-DTL-70951A (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING
4.3.2.6
Panel, cover
SHEET 1 OF 1
NUMBER
12914625
NEXT HIGHER
ASSEMBLY
12914626
CLASSIFICATION
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
None defined
Major
101
Material certification
See Note 1
3.2.6
Certification
102
Position of holes (8)
Level IV
3.2.6
AIE
103
Panel length
Level IV
3.2.6
AIE
104
Panel width
Level IV
3.2.6
AIE
105
Panel height around edges
Level IV
3.2.6
AIE
106
Position of outside holes in side of trough (4 holes)
Level IV
3.2.6
AIE
107
Position of inner holes in side of trough (4 holes)
Level IV
3.2.6
AIE
108
Width of trough (entire length)
Level IV
3.2.6
AIE
109
Position of elongated holes (2)
Level IV
3.2.6
AIE
Minor
201
Evidence of poor workmanship
Level II
3.7.1/3.7.3
Visual
Note 1: A certificate of material conformance shall be submitted by the contractor for each lot utilized. The submission of the documentation
shall be specified in the contract. Non-conformance with 3.2.1 is grounds for rejection of the lot represented by the certification.
19
