MIL-DTL-70951A (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING
4.3.2.3
Panel, base
SHEET 1 OF 1
NUMBER
12914623
NEXT HIGHER
ASSEMBLY
12914620
CLASSIFICATION
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
None defined
Major
101
Material certification
See Note 1
3.2.3
Certification
102
Diameter (8 cups)
Level IV
3.2.3
AIE
103
Position of cups (8)
Level IV
3.2.3
AIE
104
Panel length
Level IV
3.2.3
AIE
105
Panel width
Level IV
3.2.3
AIE
106
Panel height
Level IV
3.2.3
AIE
107
Position of latch-rod assembly hole (2 places)
Level IV
3.2.3
AIE
108
Diameter of large latch-rod assembly hole (2 places)
Level IV
3.2.3
AIE
109
Diameter of small latch-rod assembly hole (2
Level IV
3.2.3
AIE
places)
Minor
201
Evidence of poor workmanship
Level II
3.7.1/3.7.3
Visual
Note 1: A certificate of material conformance shall be submitted by the contractor for each lot utilized. The submission of the documentation
shall be specified in the contract. Non-conformance with 3.2.1 is grounds for rejection of the lot represented by the certification.
16
