MIL-DTL-70951 Pallet, Field Artillery ProjectileThis specification covers the requirements and provisions for the manufacturing and assembly of field artillery projectile pallets \(FAPP\) for use in unitizing 155MM projectiles \(See 6.1\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19


'Microsoft Word - MIL-DTL-70951A Pallet Field Artillery Projectile 11142007 ƒ' by neil.stern - Page 15 of 38
MIL-DTL-70951A (AR)
Conformance inspection by classification of characteristics
DRAWING
PARAGRAPH
TITLE
4.3.2.2
Latch-rod assembly, painted
SHEET 1 OF 1
NUMBER
12914630
NEXT HIGHER
ASSEMBLY
12914619
CLASSIFICATION
EXAMINATION OR TEST
CONFORMANCE
REQUIREMENT
INSPECTION
CRITERIA
PARAGRAPH
METHOD
REFERENCE
Critical
None defined
Major
101
Paint thickness, min
Level IV
3.2.2
AIE
102
Part missing or incorrectly assembled
Level IV
3.2.2
Visual
Minor
201
Evidence of poor workmanship
Level II
3.7.3
Visual
202
Protective finish missing incorrect or incorrectly
Level II
3.7.2
Visual/Measure
applied
203
Protective coating thickness
Level II
3.7.4
Visual/Measure
15
