MIL-DTL-3060G (AR)
4.3.2.1
DRAWING
Box, Ammunition, M2A1 Assembly
NUMBER
Box, Ammunition, M19A1 Assembly
7553296/7553315
NEXT HIGHER
ASSEMBLY
Examination or Test
Conformance
Requirement
Inspection
Classification
Criteria
Paragraph
Method
Critical
None Defined.
Major
101
Inside length, minimum (min.)
VL IV
3.2
Gage
102
Inside width, min.
VL IV
3.2
Gage
103
Inside height, min.
VL IV
3.2
Gage
Visual 1/
104
Incomplete manufacture
VL IV
3.2
Visual
105
Incorrect assembly
VL IV
3.2
Visual
106
Incomplete or inadequate paint coverage
VL IV
3.2
107
Burrs, rough spots, sharp projections, cracks,
Visual
splits, buckles
VL IV
3.8.1
Minor
201
AIE
Outside length, maximum (max.)
VL II
3.2
202
AIE
Outside width, max.
VL II
3.2
203
AIE
Outside height, max.
VL II
3.2
204
AIE
Concavity or convexity of cover assembly
VL II
3.2
205
AIE
Concavity or convexity of body assembly
VL II
3.2
206
Visual
Chips, dirt, grease and other foreign matter
VL II
3.8.2
207
Visual
Surface imperfections, excessive paint not dry
VL II
3.2
NOTES:
1/ Refer to MIL-STD-406 for visual defects standards. The standard defects classified as incidental shall be
considered permissible.
