MIL-DTL-2427H (AR)
PARAGRAPH
TITLE
DRAWING NUMBER
4.3.2.1
Assembly
drawing indicated by
SHEET 7 OF 7
contract
NEXT HIGHER ASSEMBLY
EXAMINATION OR TEST
Grade
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
A
B
C
REFERENCE
CRITERIA
PARAGRAPH
Minor
228
x
x
x Stain on surface of board excessive or
surface not smooth (See Note 7)
Level II
3.3.3.2
Visual
229
x
x
x Incorrect seating or operation of top
(See Note 4)
Level II
3.8.1
Visual/Manual
230
x
x
x Loose screw or screw not properly
seated (See Note 3)
Level II
3.8.1
Visual/Manual
231
x
x
x Decay
Level II
3.3.3.2
Visual/Manual
232
x
x
x Screw not of type or size required
Level II
3.5
SME
233
x
x
x Length of rope handle
Level II
3.4
SME
Note 3. A box shall be classed defective if more than one screw in any hasp or hinge, or either screw in the swivel, is not fully seated or is fully seated but can be
continuously rotated with a screw driver using normal hand pressure. The practice of hammering screws to seat them shall not be permitted, and evidence that this has
occurred is sufficient cause for classifying the box defective.
Note 4. Incorrect seating or operation of the top, which is due to improperly attached or bent hardware or improperly assembled boards and cleats, shall be cause for
rejection.
Note 7. Stain is a discoloration, occurring on or in the lumber, of any color other than the natural color of the board on which it appears. A box shall be classified
defective if it contains any boards or piece on which at least one surface is not sufficiently smooth and free of stain to permit legible marking.
- 26 -
