MIL-DTL-2439F
4.4.2.1
Container assembly
Category
Characteristic
Verification
Requirement
Inspection
Sampling
Paragraph
Method
Criteria
None defined
Critical
Major
1/
VL - III
Metal end diameter
Gage
101
VL - III
Distance from outer tube to
Gage
102
1/
end of neck tube (when
applicable)
VL - III
Hole or break in end metal
Visual
103
3.7.7
VL - III
Crimp faulty or incomplete
Visual
104
3.7.7
VL - III
Cover and outer tube fail to
Visual
105
3.2
meet
VL - III
Visual
Components missing or
106
3.17.2
incorrectly positioned or
loose
VL - III
Cuts, scuffs, gouges, checks,
107
3.17.2
Visual
or crimping cuts that
penetrate the outer layer
4.5.14.1
5 acc 0/rej1
Drop Test
108
3.17
4.5.2.3
5 acc 0/rej1
Torque Test
109
3.3.3
4.5.6.3
5 acc 0/rej1
Metal end pull test
110
3.7.2.1
4.5.5
5 acc 0/rej1
Fit of cover assembly test
111
3.6
4.5.12
5
Gloss and finish of coated
112
3.15
metal ends
1/ Dimensional requirements are listed on item drawings of individual technical data packages
(see 6.2).
16
