MIL-DTL-2427H (AR)

APPENDIX B

BOX, AMMUNITION PACKING: WOOD, NAILED

(GOVERNMENT FURNISHED)

B1. SCOPE

B1.1 This appendix prescribes the criteria to be utilized to determine the

serviceability of Government furnished boxes. This appendix is a mandatory part of the

specification.

B1.2 Classification

B1.2.1 Types, classes and grades. This appendix covers the following types,

classes and grades of box designs. (See Table IV, V and VI)

Table IV. Type I - Top opening without rope handles

Class 1

Without hardware, with two cover cleats,

See Figure 2.

Class 2

With hardware, with two cover cleats, See

Figure 3.

Class 3

Without hardware, with two cover cleats,

light construction. See Figure 2.

Table V. Type II - Top opening with two rope handles

Class 1

Without hardware, with two cover cleats.

See Figure 4.

Class 2

With hardware, with two cover cleats. See

Figure 5.

Class 3

With hardware, with three cover cleats. See

Figure 6.

Class 4

With hardware, with rope handles on cover

cleats with double end construction. See

Figure 7.

Class 5

With hardware, with double end

construction. See Figure 8.

- 50 -
